TP10S system introduction:

• 10-inch TFT high-definition and high-contrast touch screen system
• The page is simple and the large buttons are easier to operate.
• The menu-based programming style, the user interface is intuitive and friendly.
• The controller and the driver use high-speed and reliable bus communication.
• Convenient wiring and easy maintenance.
• Perfect programming can improve the efficiency of batch multi-step bending.
• Interactive alarm display.
• Optional language: Chinese, English.
• Optimized bending.
• Supports automatic calculation of bending angle and length.
• Supports angle compensation and length compensation.
• Supports escape function.
• Supports mold management.
• Can store multi-step bending sequence and products. Powerful functions
• High reliability and strong anti-interference ability
• Support valve configuration
• Soft limit function
• Manual axis shift (password protection)
• X\Y axis navigation teaching function (password protection)

With DA41T:

Machine tool performance features

• The whole machine adopts steel plate welding structure, and ANSYS stress analysis software ensures the stability and precision of the machine.
• The upper and lower molds can be segmented according to customer requirements to adapt to the processing of products of different sizes
• The servo motor that controls the back gauge and cylinder stroke is controlled by the servo driver, which can achieve higher working accuracy
• The X-axis (back gauge) and Y-axis (cylinder stroke or slider stroke) can be controlled by the system, and the system can store multiple sets of programs to facilitate the processing of subsequent products
• The DA-41S system can program the angle by inputting material length and thickness, and mold parameters
• The foot switch emergency stop function ensures that the machine stops in an emergency
• The product has high configuration, fast running speed, and more stable performance

Introduction to DA41T system

Machine standard configuration:

• Standard TP10S CNC system, manual R axis
• Fixed and removable front support
• Bending machine mold is made of 42CRMO material, with a hardness of 42 degrees, which ensures the mold life
• Quick clamp
• X axis is controlled by ball screw and linear guide

Optional:

• Photoelectric or laser protection
• Special mold
• Mechanical compensation or hydraulic compensation system
• Lighting or guardrail customization
• Automatic R axis
• Other special requirements are subject to the company's price verification

Introduction to the hydraulic system:

The hydraulic system and hydraulic components of the machine tool are imported from Germany HAWEI system. The hydraulic system is specially developed for CNC bending machines.

The system has the following features:

(1) Driven by an electro-hydraulic servo valve group, it has a compact structure, strong sealing performance, high synchronization accuracy and long service life.
(2) External large-diameter filling valve, high speed and low loss.
(3) The famous gear high-pressure pump is used to withstand high pressure and has low noise.
(4) The cylinder seal uses imported sealing elements from Japan's NOK company, which has low wear and no leakage.
(5) The hydraulic system has overload overflow safety protection.
(6) The oil level height has a clear and intuitive display.
(7) The high-precision guide system, position measurement system and hydraulic balancing function can meet the needs of full-length processing.
(8) The machine tool can work continuously under rated load, and the hydraulic system has no leakage and is continuously stable with high precision.

Motor Introduction

Nantong Pacific CNC Machine Tool Co., Ltd machines use high-efficiency and energy-saving motors from famous domestic and foreign brands such as Siemens of Germany. The efficiency of this motor is significantly higher than that of standard motors, meeting customers' needs for high-efficiency and low-energy machine tools. At the same time, we also provide optional servo motor technology, which can save up to 35% of energy using servo motors, thereby bringing customers the benefits of improved efficiency and reduced operating costs, aiming to achieve high dynamic performance and improve machine production efficiency while maintaining low energy consumption. .

Oil Pump Introduction

The oil pump of the bending machine tool is one of the cores of the bending machine, and its quality directly affects the working efficiency of the bending machine. Our oil pumps use famous domestic and foreign brands, such as sunny in the United States. It has the characteristics of high efficiency, stability and energy saving, which can improve the accuracy and speed of the bending machine, reduce noise and energy consumption, and have a long service life.

Back gauge introduction

The entire back gauge is subjected to high-temperature tempering treatment to eliminate internal stress, improve metal toughness, and prevent precision loss due to frame deformation.
To ensure high-precision movement of the X-axis of the machine back gauge, our suppliers are all well-known brands, such as HIWIN. Ball screws and linear guides improve the accuracy and consistency of the machine. Our back gauge is controlled by a servo motor, which provides better control and operating accuracy than stepper motors.

Electrical components

We use genuine Schneider or German Siemens components imported from France, which are very stable and durable. The original electrical cabinet equipped with this machine has strong anti-interference ability and stable electrical performance.

Quick clamps

Very tightening, positioning and precision. Can be replaced quickly and easily, so as to achieve efficient use of time.

Standard configuration

1. Standard configuration is 4-axis (Y1, Y2, X, R) CNC bending machine. Manual tie rod compensation workbench is standard for 3200mm and above.
2. Removable front support
3. The bending machine adopts segmented mold. Made of 42CRMO material, with a hardness of 42 degrees, the mold life is guaranteed
4. Quick clamp
5. The main motor adopts German Siemens or well-known brands, the hydraulic system adopts German Rexroth (BOSCH-REXROTH), and the main electrical components adopt French Schneider or German Siemens.

Optional configurations for electro-hydraulic bending machines:

1. Specially customized upper and lower molds
2. WILA hydraulic clamping system or pneumatic clamping
3. Laser protector or infrared protection
4. Manual compensation, electric compensation or hydraulic compensation
5. Main motor upgraded to servo motor
6. Double-side or rear side guardrails
7. LED lights added to the machine tool
8. Optional CNC axis addition
Other special requirements are subject to the company's price verification

Applicable field

Suitable for drawing, punching (including optional punching buffer), bending, flanging, cold extrusion and other stamping processes for metal materials, or for press forming of correction, press-fit, powder products and abrasive products. And plastic products, compression molding of insulating materials.

Optional accessories

• Mobile workbench
• Blanking buffer device
• Photoelectric protection device
• Stroke, pressure, speed digital display, numerical control device
• Touch industrial display
• Hydraulic system heating and cooling device
• Feeding device
• Slider safety plug
• Mold heating and temperature control device
• PLC programmable controller
